Broadcast Lenses
Canon CJ27ex7.3B IASE T
Work decisively with a 27x 7.3-197mm zoom and a 2.0x Extender. Equipped with a new generation digital drive unit, CJ27ex7.3B IASE T gives an even greater zoom range, plus extra versatility.
Fast. Precise. Versatile.
The CJ27ex7.3B IASE T and eXs-V drive unit together offer greater flexibility thanks to a 27x 7.3-197mm zoom and 2.0x Extender plus the re-engineered new generation drive unit's fast servo operation and remote capabilities. Take advantage of this enhanced performance and add more power to your footage.
See full specification-
A wider zoom and telephoto reach
Cover more thanks to a wide 7.3mm angle of view and a 197mm telephoto reach. The CJ27ex7.3B IASE T delivers class-leading magnification with a powerful 27x zoom and 2.0x Extender.
-
Incredible Canon premium optical quality
Capture high quality 4K HDR footage from screen centre to screen edge thanks to Canon's advanced optical technologies such as a multi-group zoom and floating focus system, which produce higher resolution imagery. Coating technology and chromatic aberration correction ensure sharp and accurate subject rendering.
-
Re-engineered digital drive unit
Shoot with precision thanks to fast servo control and thoughtful ergonomics for a more intuitive performance. Multiple interfaces including three 20-pin connectors and USB-C allow for remote control and firmware updates, while a 16-bit encoder delivers precise lens data output for virtual productions.
-
Light weight and compact size
A 2.10kg1 lightweight, robust body offers exceptional durability and is further enhanced by superior ergonomics for maximum operator comfort.
Specifications
-
UHDxs optical quality
Outstanding 4K HDR image quality from the centre to the edge of the image
-
7.3-197mm zoom range
Excellent wide-angle and telephoto versatility
-
Re-engineered Digital Drive Unit
Enhanced with fast servo and a wealth of additional features
-
f/1.8-f/2.95 maximum aperture
Fast and bright for low light situations
-
Built-in 2x Extender
Enables a maximum reach of 394mm
eXs-V Digital Drive Unit
-
Improved servo performance
A faster servo than the previous drive unit allows for a more responsive iris, which, along with the renowned focus and zoom speeds, making the eXs-V drive optimised for sports broadcasts and live events.
-
Re-engineered design
An intuitive grip matches the shape of a hand for comfortable support during longer periods, while a repositioned display on the top of the unit gives better visibility when shooting.
-
Remote extender support
When shooting remotely from a crane or other device, the extender can be controlled from the operator via an optional switch box.
-
USB-C connectivity
Provides multiple benefits including remote lens control, firmware updates and outputting lens data and saved user settings
-
Compatible with ZSD-300D and FPD-400D
The drive unit maintains compatibility with traditional Canon broadcast demands.
-
Focus breathing compensation
Ensure your angle of view is consistent no matter the change in focus settings
-
Support Virtual Systems and Remote Control
The new drive unit has multiple interfaces for remote shooting plus a high resolution 16-bit encoder for accurate lens data output.
-
Improved ergonomics
Three 20-pin connectors, with one conveniently placed diagonally across the rear, ensures easier integration with other connections, such as Canon zoom and focus demands.
What’s in the box
Everything you need to capture high quality 4K HDR footage on the move
-
Lens main unit
-
Drive unit
-
Hood unit
-
Lens cap
-
Dust cap
-
Hood cap
